6" x 2" Metal Track Caster - Ductile Steel Wheel - V-Groove Caster 1250 lb. Capacity - Rigid - - 1

6" x 2" Ductile Steel Wheel - V-Groove Caster 1250 lb. Capacity - Rigid


For heavy duty and heavy loads.

V-groove caster wheels are designed to guide equipment by rolling on inverted angle iron track. Elevated track minimizes problems caused by floor debris. The relief groove at the base of the "V" equalizes the load on each face of the angle. When not operating on track, the considerable wheel tread on each side of the V-groove allows for use on smooth floors.

Cast iron/Semi-steel wheel offers a strong, resilient, cost effective solution for heavy loads. The hard tread rolls easily and allows high abrasion resistance; Smooth face allows for symmetrical ride.

Call us at 800-262-2807 if you need any help (Mon - Fri 7:30am - 4:30pm CST)

Part Number: J-P5006201152

Technical Specs

Metric Specs Metric Specs
Max Capacity 1,250 lb. Frame Material Standard Iron
Wheel Diameter 6” Hub length 2-3/16"
Wheel Width 2" Bearing Bearing Included
Overall Height 7-1/2" Fits Axle Axle Included
Groove Width 7/8" Mounting Type Plate (Zink finished)
Rigid/Swivel Rigid Top Plate Size 4" x 4-1/2"
Swivel Radius N/A Hole Spacing 2-5/8" x 3-5/8" slotted to 3"x 3"
Wheel Material Ductile Steel Attaching Bolt Size 3/8"
Wheel Color Dark Red
