Mappcaster
4-15/16" x 1-7/16" Flanged Cast Iron Wheel Kingpinless Rigid Caster - 1,500 Lbs Capacity
P50052CIFL
4-15/16" x 1-7/16" Flanged Cast Iron Wheel Kingpinless Rigid Caster - Part # P50052CIFL
Cast Iron Flanged wheels are designed to roll on rails and come with extra thick treads, hubs & walls. Cast Iron is the standard metal wheel used by most unless a heavier capacity or greater impact strength metal wheel is needed. While cast iron is very strong, it is tough on floors & could lead to floor damage. For applications requiring more capacity or impact strength, check out the ductile steel & forged steel wheel caster options.
Recommended Rail Type: ASCE 16
* Please note temperature ratings are dependent upon the bearing selected. Unless noted otherwise in the options, bearings will have a 180°F temperature rating.
Specifications:
| Load Capacity (lbs.): 1,500 | Link to Matching Swivel Caster: Contact Us |
|
Inner Wheel Diameter: 4-15/16" Outer Wheel Diameter: 5-11/16" |
Caster Rig Material Type: Cold Rolled Steel |
|
Overall Tread Width: 2-1/8" Roll-able Tread Width: 1-7/16" Flange Width: 11/16" |
Caster Rig Color/Finish: Bright Zinc Plated |
| Wheel Type: Cast Iron | Swivel or Rigid Caster: Rigid |
| Wheel Bearing Type: Roller | Swivel Radius: N/A |
| Overall Height: 6-1/2" | Swivel Construction: N/A |
| Temp Range: -45°F to 600°F | Mounting Plate: 4" x 4-1/2" |
| Wheel Hardness: Brinell 188 | Bolt Hole Pattern: 2-5/8" x 3-5/8" slotted to 3"x 3" |
|
Wheel Color: Red |
Mounting Bolt Size: 3/8" or Smaller |
| Link to Replacement Wheel: KWFT-51H-3/4 | Weight : 8.962 lbs. |
