8" x 3" Forged Steel Wheel - V-Groove Swivel Caster - 5000 lb. Capacity - Plated
J-P8008301251
The machined cold rolled steel (forged steel) wheel is the ultimate heavy duty wheel, ideal for maximum weight capacity, impact strength, durability, abrasion resistance, and roll-ability of all caster wheels.
This V-groove wheel is one of our most durable wheels. The wheel also has a zinc plating to resist rust. It is most often used with ongoing usage applications such as sliding gates or attached to heavy equipment.
V-groove caster wheels are designed to guide equipment by rolling on inverted angle iron track. Elevated track minimizes problems caused by floor debris. The relief groove at the base of the "V" equalizes the load on each face of the angle. When not operating on track, the considerable wheel tread on each side of the V-groove allows for use on smooth floors.
- 1-3/8" V-groove width, 11/16" depth
- 5000 lbs. capacity
- Temperature range: Up to 1,300° F. (with high temp bearing option)
- Caster Concept Rig
-
10-1/2" total height
Call us at 800-262-2807 if you need any help.
Part Number: J-P8008301251
More Technical Specs
| Metric | Specs | Metric | Specs |
|---|---|---|---|
| Max Capacity | 5,000 lb. | Frame Material | Standard Iron |
| Wheel Diameter | 8” | Hub length | 3-1/4" |
| Wheel Width | 3" | Bearing | Included |
| Overall Height | 10-1/2" | Fits Axle | Axle Included |
| Groove Width | 1-3/8" | Mounting Type | Plate (Zink finished) |
| Rigid/Swivel | Swivel | Top Plate Size | 6" x 7.5" |
| Swivel Radius | 2-1/2" | Hole Spacing | 4.5" x 5" |
| Wheel Material | Forged Steel | Attaching Bolt Size | 1/2" |
| Wheel Color | Silver/Yellow Zinc |
