4" x 1-3/4" Solid Steel V-Groove Wheel - 3,000 Lbs Capacity
PAH108
4" x 1-3/4" Solid Steel V-Groove Wheel - Part # PAH108
This Solid Steel V-groove wheel provides exceptionally low rolling resistance, outstanding wear resistance, and extremely high static and dynamic load capacity. This heavy duty zinc plated wheel can be used in many applications and is very popular for automatic gates.
V-groove wheels are designed to guide equipment by rolling on inverted angle iron track. Please note if more than one track is being used, it is critical for the tracks to be parallel, strait and level. Otherwise the wheels could bind or derail. Recommend track tolerance is 1/64" per 20 Feet.
Specifications:
 Capacity: 3,000 Lbs. |
 Wheel Type:Solid Steel V-Groove |
 Wheel Diameter:4" |
 Hub Length (without Bearings):N/A |
 Tread Width:1-3/4" |
 Hub Length (with Bearings):2" |
 Groove Width:7/8" |
 Groove Depth: 7/16" |
 Bearing Type:Ball Bearing |
 Wheel Durometer:Rockwell 89-93 B |
 Plain Bore ID:N/A |
 Wheel Tread Shape:V-Groove |
 Accepted Axle/Bearing ID:1/2" |
 Wheel Color:Silver |
 Temp Range: -40˚F to 550˚F |
 Weight: 5 lbs |
|
Capacity:3,000 lbs. |
|
Wheel Type:Solid Steel V-Groove |
|
Wheel Diameter:4" |
|
Tread Width:1-3/4" |
|
Hub Length (without Bearings):
N/A |
|
Hub Length (with Bearings): 2"
|
|
Groove Width: 7/8"
|
|
Groove Depth: 7/16"
|
|
Bearing Type:Ball Bearing |
|
Plain Bore ID:N/A |
|
Accepted Axle/Bearing ID:1/2" |
|
Wheel Durometer:Rockwell 89-93 B |
|
Wheel Tread Shape:V-Groove |
|
Temp Range: -40˚F to 550˚F |
|
Wheel Color:Silver |
|
Weight: 5 lbs |
